The ADQUAD77 has live display options during quad recording. Comprehensive alarm capabilities. Operational functions that users demand most. The ADQUAD77 offers the performance, flexibility and control demanded by today’s security professionals. View up to four live cameras simultaneously, sequence through all or selected cameras, or select one camera for full-screen display while recording to VCR in quad format. Comprehensive alarm features include full screen display of alarmed camera, programmable duration, alarm disable, alarm output and audible alert. Quickly access time, date, camera title and other functions via two-screen set-up menu. The ADQUAD77 featuires high resolution, simple operation and high performance.

Features
View real-time images on live monitor while recording to VCR
Automatic sequential switching with variable dwell and camera selection
Easy set-up and operation via push-button controls on front panel
Time, date and camera title displays on live monitor
Adjustable video gain control for each camera
Comprehensive alarm features plus universal alarm and remote connectors, video loss indication, security lock
Unmatched clarity with 512 x 512 high resolution digital pixel images to display monitor and VCR

Specifications
Model: ADQUAD77
Video Standard NTSC/EIA: 525 lines, 60 fields/second
Video Input: Four, 1.0 V p-p composite video
Monitor Output: 1.0 V p-p composite video
VCR Input: 1.0 V p-p, 75 ohms, BNC
VCR Output: 1.0 V p-p composite, 75 ohms, BNC
Digital Memory: 512 x 512 pixels full screen to display and VCR, 8 bit Luma, 64 shades of gray, 24-bit Chroma, 16,000,000 colors on palette
Display Rate: Real-Time, 30 Fields Per Second
Alarm Input: Four, Programmable as Normally Open or Normally Closed, Enable/Disable
Alarm Hold Input: +5 to +15 VDC or CMOS/TTL Active High
Alarm Output:Form C, 2A @ 30 VDC or 1A @ 125 VAC, Resistive
Alarm I/O Connector: One, DB9
Alarm Duration: Programmable 0 seconds to 59 minutes or continuous, 4 second default
Operating Power: 12 VDC, 18 watts, 2.1mm Pin Jack
Unit Weight: 3.9 lbs. (1.8 kg.)
Shipping Weight: 7.0 lbs. (3.2 kg.)
Dimensions: 1.75 in. H x 8.5 in. W x 12.25 in. D (44mm x 216mm x 311mm)
Operating Temperature: 32° to 113° F (0° to 45° C)


Product Specification Sheet
