Panasonic WV-CP630
Panasonic WV-CP630

Panasonic WV-CP630

Panasonic WV-CP630
Click to enlarge image(s)
The Panasonic WV-CP630 CCTV Camera delivers superior image by fusion of Super Dynamic and ABS. ABF (Auto Back Focus) ensures easy installation and stable focus in both color and B/W modes. It features the 3-dimensional color conversion function for natural color reproduction even in lower color temperature situation.

Signal System: NTSC
Image Sensor: 1/3" Color IT CCD
Resolution:
Color: 700 TVL
Number of Pixels : 976 x 494
Lens: CS-mount
Iris Operation: Auto iris DC
Minimum Illumination: Color: 0.08 lux (SENS UP: OFF), 0.003 lux (SENS UP: 32x) at F1.4
B/W: 0.008 lux (SENS UP: OFF), 0.0003 lux (SENS UP: 32x) at F1.4
Signal-to-Noise Ratio: 52dB (Super Dynamic ON)
Sync: Internal (INT), Multiplexed Vertical Drive (VD2), Line-Lock (LL)
Video Output: BNC (multiplexed VD2 and control data capable)
Audio Output: N/A
Motion Detection: Off / Motion Detection / Scene Change
Alarm I/O: ALARM IN: 1 (OFF / ALARM / VMD PERMIT / BW / SCENE2)
ALARM OUT: 1 (OFF / ALARM / BW)
Power Requirements: 120VAC
Operating Temperature: -10ºC ~ +50ºC (14F ~ 122F)
Dimensions (WxHxD): 3 x 2.6 x 5.2" (75 x 65 x 133mm)
Weight: 1 lb (430g)


Product Specification Sheet
